Abaqus can use NVIDIA GPUs for parts of Abaqus/Standard workflows. It doesn’t speed up every model, and setup details matter. This guide shows how to run it cleanly, what tends to benefit, and how to avoid the usual snags.
What this covers
- Picking a CUDA‑ready template on your preferred GPU renter
- Wiring your FlexNet license safely
- Installing or mounting Abaqus (we don’t redistribute it)
- Enabling GPU acceleration for Abaqus/Standard
- What typically benefits (and what doesn’t)
- Validation, self‑benchmarking, and troubleshooting
Versions differ. Always align with your release notes for exact feature coverage and flags.\
Start in seconds with the fastest, most affordable cloud GPU clusters.
Launch an instance in under a minute. Enjoy flexible pricing, powerful hardware, and 24/7 support. Scale as you grow—no long-term commitment needed.
1) Choose a CUDA‑ready template
Usually on GPU renters, your job runs inside a container. You do not need Docker‑in‑Docker; the host driver is passed through.
- General base: Ubuntu 24.04 LTS (CUDA 12.6)
- Your own image: a private image with your org’s tools. Add envs:
NVIDIA_VISIBLE_DEVICES=allNVIDIA_DRIVER_CAPABILITIES=compute,utility
Sanity check inside the running container:
nvidia-smi
2) Wire licensing (FlexNet)
Set the environment variable in your template and connect via VPN or SSH tunnel per your IT policy (see the licensing guide):
ABAQUSLM_LICENSE_FILE=27002@licenses.my-org.edu # example port@server
If tunneling, use 27002@localhost with the exact port you forwarded.
3) Install or mount Abaqus
Bring Abaqus yourself.
- Install in the container: mount the installer, run the Linux installer, keep the image private.
- Mount from a shared volume: if your org provides a network install, mount it read‑only and set
PATH/wrappers accordingly.
Keep license files and installers out of public images. Mount secrets at runtime.
4) Enable GPU acceleration (Abaqus/Standard)
GPU use is configured at launch and/or via your version’s environment settings. A common pattern is to request a GPU when starting a Standard analysis. Example skeleton:
# Example: launch a Standard analysis with CPUs+GPU (adjust to your version)
abaqus job=model input=model.inp cpus=8 gpus=1 interactive
Notes:
- The .inp determines Standard vs Explicit via its step definitions. GPU coverage applies to Abaqus/Standard.
- Some releases expose GPU settings via environment files or resource keywords; newer ones accept a
gpus=<N>style launch argument. Check your version docs. - Start with single GPU and a modest CPU thread count; profile before scaling.
Verify it’s active
- Watch
nvidia-smiduring the solve. - Check the job log/messages for lines indicating GPU initialization/offload.
5) What typically benefits (and what doesn’t)
Likely to benefit
- Large linear systems where the iterative solver dominates
- Models with elements/operations covered by the GPU kernels in your release
- Single‑node runs where VRAM comfortably holds key working sets
Less likely to benefit
- Small models dominated by setup/I/O
- Solver paths not covered by GPU in your version
- Workflows that truly require double‑precision throughput beyond what consumer GPUs offer (consider FP64‑strong GPUs/CPUs)
6) Validate before scaling
Run a representative case on CPU only and CPU+GPU with identical settings.
- Compare residual histories and key response metrics (displacements, stresses) within your acceptance bands.
- Record wall‑clock, iterations/second.
- Compute cost per converged case:
cost_per_case = price_per_hour × wall_hours
Keep a short Methods block with: Abaqus version, job command, CPU threads, GPUs, GPU model/VRAM, and the instance/image details.
7) Troubleshooting
“GPU not detected / failed to initialize”
Confirm nvidia-smi works, the container is CUDA‑ready, and you launched a Standard job with GPU enabled for your version.
“No speedup”
Your model may be on a solver path the GPU doesn’t accelerate, or it’s too small/IO‑bound. Profile with CPU vs CPU+GPU and decide pragmatically.
Out of memory (VRAM)
Use a GPU with more VRAM, reduce outputs, or adjust model size within validation constraints.
License errors
Check ABAQUSLM_LICENSE_FILE and network reachability (VPN/tunnel). See the licensing guide.
Methods snippet (copy‑paste)
hardware:
gpu: "<model> (<VRAM> GB)"
driver: "<NVIDIA driver>"
cuda: "<CUDA version>"
cpu: "<model / cores>"
software:
abaqus: "<version> (Standard)"
image: "Ubuntu 24.04 LTS (CUDA 12.6)"
licenses:
ABAQUSLM_LICENSE_FILE: "27002@licenses.my-org.edu"
run:
cmd: "abaqus job=model input=model.inp cpus=8 gpus=1 interactive"
notes: "single GPU; Standard solver"
outputs:
wall_hours: "<hh:mm>"
iters_per_sec: "<…>"
convergence: "<criteria>"
